5 inch Round TFT LCD Display – 800*480, RGB Interface

Image Reversion: UP/DOWN and LEFT/RIGHT
Size: 5 inch lcd display
Resolution: 800*480
Interface: RGB

SKU: RV050WVM-720-50 Category: Sunlight Readable Display

Description
Additional information

Description

The model RV050WVM-720-50 is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device. This model is composed of a TFT LCD panel, a driving circuit and a back light system. This TFT LCD has a 5.0(15:9) inch diagonally measured active display area with (800 horizontal by 480 vertical pixel) resolution.

Model	RVO5OWVM-72O-50
Size	5 inch lcd display
Number of Pixel	800 RGB (H) x480(V)
Display area	108(H) x64.8(V)
Module Outline Dimension	120.70X 75.8 x4.5(Typ)
Display mode	Normally Black , IPS
Pixel arrangement	RGB Vertical stripe
Pixel pitch	0.135(H) xO.135(V)
Back-light	LED Side-light type
Interface	RGB
Luminance	750 Cd/m2
Storage temperature	-35-85 °C
Operating temperature	-30-80 °C
