6.75 inch High-brightness TFT LCD Display – 1000nit Brightness, 1024*600 Resolution, LVDS Interface

  • Size: 6.7 inch TFT LCD module
  • Resolution: 1024*600
  • Brightness: 1000nit
  • Contrast Ratio: 1200
  • NTSC: 60%
  • Interface: LVDS
SKU: RV067WSM-K10-40 Category:

Description



Model RV067WSM-K10-40
Size 6.75 inch TFT LCD module
Panel Type IPS
Resolution 1024xRGBx600
Display Mode Normally Black
Number of Colors 16.7M
Viewing Direction ALL
NTSC 60%
Contrast Ratio 1200
Luminance 1000 cd/m2
Module Size 161(H)x91.1(V)x4.8(D)
Panel Active Area 151.76X79.8
Pixel Arrangement RGB-stripe
Light Source 36 LED light
Interface LVDS
Operating Temperature -30~+85 ℃
Storage Temperature -30~+85 ℃
