6.95 inch TFT LCD Display – 600*1024 Panel, MIPI Interface

  • Size: 6.95 inch TFT LCD module
  • Resolution: 600*1024
  • Interface: MIPI
  • Contrast Ratio: 1000:1
  • Luminance: 300 cd/m2
  • Driver IC: ICML9707
SKU: RV070WSM-300-31 Category:

Description

This is a TFT LCD module, 600*1024 resolution, MIPI interface 300nit brightness, 31 pin.

Model RV070WSM-300-31
Size 6.95 inch TFT LCD module
Panel Type IPS
Resolution 600xRGBx1024
Display Mode Normally Black
Number of Colors 16.7M
Viewing Direction ALL
NTSC 50%
Contrast Ratio 1000
Luminance 300 cd/m2
Module Size 94.88(H)x163.18(V)x2.39(D
Panel Active Area 89.28X152.37
Pixel Pitch 148.8×148.8
Pixel Arrangement RGB-stripe
Driver IC ICML9707
Light Source 18 LED light
Interface MIPI
Operating Temperature -20~+70 ℃
Storage Temperature -30~+80 ℃



Additional information

Size(inch)

6.95
Brightness (cd/m²)

300
Resolution

1024×600
Interface

MIPI
Viewing Angle

All
